Refractory Castables
Owing to our years of experience and in-depth knowledge of this domain, we are manufacturing and exporting a qualitative range of Industrial Castables. The offered range of castables is processed by our professionals using premium quality ingredients that are procured from the reliable vendors of the market.
These castables are widely appreciated among the patrons for their brilliant attributes such as purity, effectiveness and accurate composition. Below mentioned are the products, we are offering in this range:
Leveraging on our year of experience and in-depth knowledge of this domain, we are offering excellent quality High Purity & Dense Castables. Our experienced professionals have processed these High Purity & Dense Castables using excellent quality ingredients that are procured from the reliable vendors of the market.
| Brand name | Avon Heat |
Avon Heat |
Avon Heat |
Avon Heat |
Avon Crete Normal |
Avon Crete Super |
Avon Crete Special |
|
Physical Properties |
||||||||
| Recommended TempC (max) | 1750 | 1600 | 1500 | 1700 | 1400 | 1450 | 1350 | |
| RefractorinessC / Orton (min) | 1820/37 | 1683/31 | 1665/30 | 1800/36 | 1580 | 1680 | 1450 | |
| Dry Density kg/m3 (min) | 2800 | 2200 | 2100 | 2600 | 2100 | 2500 | 2250 | |
| Linear Change % (max) | 1.0 1550 C/3 hrs |
1.5 1550 C/3 hrs |
1.0 1550 C/3 hrs |
1.0 1550 C/3 hrs |
1.0 1400 C/2 hrs |
1.0 1400 C/3 hrs |
0.8 1350 C/2 hrs |
|
| CCS kg/cm2 (min) | 110C | 600 | 350 | 350 | 350 | 250 | 350 | 400 |
| 1350C | - | - | - | - | 225 | - | 300 | |
| 1450C | - | - | - | - | - | 450 | - | |
| Maximum Grain Size mm | 5 | 5 | 5 | 5 | 5 | 5 | 5* | |
Chemical Analysis |
||||||||
| % Al2O3 | 90 | 60 | 50 | 80 | 45 | 70 | 45 | |
| % Fe2O3 | 0.8 | 1.0 | 1.5 | 1.5 | 4 | 5 | 4 | |
